BG06 Parking Automated Boom Barrier Gate Automation Systems Intelligent Road Gate
“Upgrade your parking lot management system with our high-speed Boom barrier gate. Intelligent, anti-smash, and power failure lifting for efficient control. Contact us now!”
- Description
- Packaging Details
- Reviews (1)
Description
Types of poles supported by automatic barriers gate(customisable)
Pole length available 1m 2m 3m 4m 5m 6m
Optional accessories
The drive unit is electromechanical, allowing for manual operation with a release gear mechanism during power failures. Controlled electronics enable raise/lower functions using various access methods such as card readers, biometric readers (fingerprint or hand shape), radio control, and on/off key switches. Additionally, safety accessories like photocells, inductive loop detectors, flashing lights, and red/green lights can be seamlessly integrated into the system.
| Vehicle access gate parameters | Produced by Sean Liu |
|---|---|
| Operating Voltage | Using DC24V safe voltage power supply, breaking the traditional 220V power supply mode of barrier gates, the product is safer and more reliable to use. |
| Operating power consumption | 100W |
| Working current | 5A |
| Insulation level | Class F |
| life span | ≥5 million times |
| working environment | Temperature range: -30℃~+60℃ (special customization is required below -30℃) |
| Temperature: below 85% | |
| Altitude: below 1000M | |
| Running speed | The speed of the lifting gate is adjustable (0.8-6S), and it can adjust fast lifting and slow landing to meet the needs of various environmental situations (community, industrial park, highway, unattended system, etc.). |
| Limiting method | Limit switch-free. The entire lifting and lowering stroke of the gate lever is digitally controlled to avoid the cumbersome process of mechanical limit adjustment. |
| Anti-smash function | The unique anti-smashing function is completely digitally monitored. The force and reaction time of the smashing rod are adjustable, and the entire process does not require the addition of any auxiliary equipment. |
| The main controller is designed and manufactured with a highly reliable microprocessor. | |
| Adopting specially designed 24V special brushless motor. | material:Cold rolled steel 1.5 |
| Motor rated power: 100W pure copper motor | Motor rated speed: 1500/min |
| Motor rated torque: 20N-m | Standard rod length: straight rod within 4 meters |
| Running noise: ≤60dB | Gear lever up and down time: 1~6S |
| Running life: ≥5 million times | Automotive paint finish for durability |
| Delivered with 2 remote controls |
Configuration List：
- Barrier Gate – 1 unit
- Remote Controllers – 2 units
- Product Manual – 1 copy
- Certificate of Conformity – 1 copy
application scenario：
With night breathing light DC brushless motor BG06 digital Barrier Gate is a series of new-generation intelligent road gates that can adapt to modern “safe, fast, efficient and high quality” management, which is carefully designed and produced by our company; its high standard, high quality, high integration characteristics, fashionable appearance and its unique visual charm give people a sense of dignity and elegance, and make the matching with it more complementary effect, which is the first choice for supporting occasions such as parking lots, hotels, schools, garden villa communities, enterprises and public institutions. It is the first choice for parking lots, hotels, schools, garden villa communities, enterprises and institutions.
- Simple: the crank linkage mechanism drive, reducing institutional failure, low noise, no pollution, no maintenance
- High sensitivity magnetic limit control system, low-voltage DC control, safe and reliable, limit accuracy
- Long rod gate has special manual and automatic starting device for power failure.
- Special balancing mechanism, always keep the starting pole vertical, falling pole level, and smooth, non-equivalent speed operation eliminates the phenomenon of the gate pole lifting process and starting the phenomenon of the gate pole accelerated too fast.
- The chassis adopts powder coating, anti-ultraviolet rays, sun exposure is not easy to change color.
- The road gate pole adopts high-strength aluminum alloy tube, outsourced vibration-resistant and anti-collision foam rubber, the surface with yellow and black reflective film, eye-catching reflective effect can warn the driver in time.
- advanced motor, with overheating protection, machine temperature is greater than 135 degrees automatically cut off the power supply, the motor will not easily burn out!
- Service life of more than 5 million times.
The gate consists of three parts, namely, chassis, movement and control part. The movement part is mainly to realize the upward and downward movement of the gate, which is composed of motor, speed reducer, four-link mechanism, balancing mechanism, gate lever, etc.; the control part is mainly to control the direction and position of the movement of the gate, i.e., to control the rising, falling and stopping of the gate.
There are two ways to control the gate, i.e. manual and automatic control. Manual control of the gate is the rise and fall of the gate pole by the hand control button or remote control to operate; automatic control of the gate is the rise of the gate pole by the hand control \ remote control \ control machine control, down by the sensor detection after the automatic fall pole.
Breathing light with night DC brushless motor Bounce back when blocked anti-smash function
| Detail | Information |
|---|---|
| Brand Name | ParkingLPR |
| Place of Origin | Shenzhen, China |
| Price | Negotiable |
| Certification | CE,ISO |
| OEM & ODM | Support |
| Packaging Details | Packed In Bubble Wrap Firstly, And Then Reinforced With Carton For Outer Packing. |
| Minimum Order Quantity | 1 Piece |
| Supply Ability | 3000 Pieces per Month |
| Delivery Time | 3-13 Working Days after Receiving Your Payment |
| Payment Terms | T/T, Western Union, MoneyGram, Alibaba Trade Assurance, PayPal, etc. |
| Customization | All products are customizable, with a minimum order quantity of 50 pieces for customized items. |
1 review for BG06 Parking Automated Boom Barrier Gate Automation Systems Intelligent Road Gate
Add a review
Product FAQ
Q. What’S Your Main Product?
Our Main Products Are Parking Lot Equipment, Such As Smart Parking Barriers, License Plate Recognition, Access Gates, Electric Vehicle Chargers, Etc.
Q.How About Your After-Sales Policy?
A:Customer First Is Our Always Principle . All Of Our Products Normal Warranty Is 12 months. We Give Necessary Back Or Video Guidance For Daily Problems. If Massive Products Occur Big Quality Problems. Our Technical And Engineer Support Overseas Service .
Q: Are You Manufacturer Or Trader?
A:We Are Manufacturer, We Parkinglpr Have Own Factory In Shenzhen, We Have Independent Department For Purchasing, Producing, Processing, Testing, Packing, Storing , And Transportation, Believe Our Team Is Best Team In China.
